ProX Single Speed Wheel Carbon Fixie Wheelset Flip Flop Hub Novatec

• Fixed gear Novatec flip flop hubs

• With/Without brake surface optional

• Pillar 1423 spokes, aero and strong

• 28mm and 25mm width carbon rims optional

• Compatible for 700*25C-45C tire (tubeless ready)

  • Item NO.:

    Novatec FX Wheels

  • Payment:

    Paypal, Bank Transfer

  • Origin:

    China

  • Color:

    UD/3K/12K(Customized Decal Acceptable)
Inquiry now
DESCRIPTION

ProX Carbon Single Speed/Fixie Wheelset With Novatec Flip Flop Hub

If you're a cyclist fan, you will be familiar with the difference between fixed grear wheels(single speed) and common freewheel bikes. A fixie wheel bike relies on you constantly pedaling, no gears to adjust. Thanks to this, you can pedal quickly without the risk of slipping gears, which increases your energy efficiency. Due to its tidy and vintage feature, it comes popular among streets, track, daily commuting etc. in the fashion industry.


Where to find the fixed gear wheels that won't break the bank? Here is the right place!
We use Novatec flip flop hub. There are threaded area to fit both fixed gear cogs and freewheel on two sides of rear hub. It means, the same wheel can be used for either fixed gear or single speed by just reversing two sides of rear hub.

Ride fixed gear: Wheels will not move forward unless you keep pedalling.
Ride single speed: buy the freewheel and install it on the other side. By turning the rear wheel around, it's for single speed riding. Then the pedals can remain stationary while the bicycle is forward.
The Novatec A165/A166 hub is with front 20H/rear 24H and 17T fixed cog is included free. The hubs weigh 611g including 58g cog.
For riders who want to switch bike to a single speed style, freewheel option is recommended for starting. After practice and getting comfortable, it's a right time to try fixed gear option.

ProX single speed fixie carbon wheel with flip flop hub

ProX provides two width option for our Novatec fixie wheels. That is, 28mm width carbon clincher rims, and 25mm width carbon rims clincher.
Both series rims are with high TG 3K grooved braking track, which provides more friction, shorten about 30% braking distance, faster heat elimination.
The 28mm width rim series (model PRV28) is with 28mm outer (21mm inner) width. For such wide road rims, the optimized aerodynamics tire size is 700*28C. If you plan to use 28C (or wider) tire, PRV28 rim series is recommended.
The 25mm width rim series (model PRV25) is with 25mm outer (18mm inner) width. For such wide road rims, the optimized aerodynamics tire size is 700*25C. If you plan to use 25C tire, PRV25 rim series is recommended.
For safety's sake, most fixed gear wheels have a front brake, and some have two brake and some even have no brakes at all. ProX provide the rim brake and no rim brake options to meet your needs.

Although these aren't the lightest wheels on the market, the decent quality of the components and the options available make these attractive for a casual or commuter cyclist.

SPECIFICATION

ProX Economic Fixed Gear Carbon Wheels With Novatec Flip Flop Hub Specification:

-Wheels For: 700C Single Speed/Fixed Gear Bikes
-Rims Material: Carbon Fiber T700
-Braking Track: With / WITHOUT brake surface optional
-Hubs: Novatec A165/A166 flip flop hub(black color, no logo)
-O.L.D: front 100mm/rear 120mm

-Axle: front M9*140mm hollow/rear M10*165mm hollow
-Type: J Bend
-Fixie Cog: 17T

-Compatible Speed: Single Speed
-Spoke Hole Count: front 20H/rear 24H or front 24H/rear 24H
-Tire Type:Clincher/tubeless ready
-Spoke: Pillar 1423
-Spoke Tension(recommended): ≤130kgf
-Tire Pressure: 125psi/8.6bar
-Warranty Year: 2 years


ProX Single Speed Fixie Carbon Wheelset Built With 28mm Width Rims

Model Rim Depth Outer Width Tire Type Hub Front Size Rear Size Spoke
Rear SizeTire Size

(Recommended)

SpokeWeight

(+/-3%)

FX165-PRV28-33C-1423 PRV28-33C 33mm 28mm Tubeless or Clincher Novatec A165/A166 9*100mm 10*120mm Pillar 1423 700*28C-45C 1765g
FX165-PRV28-38C-1423 PRV28-38C 38mm 28mm Tubeless or Clincher Novatec A165/A166 9*100mm 10*120mm Pillar 1423 700*28C-45C 1785g
FX165-PRV28-44C-1423 PRV28-44C 44mm 28mm Tubeless or Clincher Novatec A165/A166 9*100mm 10*120mm Pillar 1423 700*28C-45C 1805g
FX165-PRV28-50C-1423 PRV28-50C 50mm 28mm Tubeless or Clincher Novatec A165/A166 9*100mm 10*120mm Pillar 1423 700*28C-45C 1865g
FX165-PRV28-55C-1423 PRV28-55C 55mm 28mm Tubeless or Clincher Novatec A165/A166 9*100mm 10*120mm Pillar 1423 700*28C-45C 1905g


700C Carbon Clincher Rims 28mm Width

Rims PRV28-33C PRV28-38C PRV28-44C PRV28-50C PRV28-55C
Max Weight Limit 105kg/230lb 105kg/230lb 110kg/240lb 110kg/240lb 110kg/240lb
Material T700 T700 T700 T700 T700
Sectional Drawing fixie bike wheelset 33mm depth fixie bike wheelset 38mm depth fixie bike wheelset 44mm depth fixie bike wheelset 50mm depth fixie bike wheelset 55mm depth


ProX Single Speed Fixie Carbon Wheels Built With 25mm Width Rims

Model Rim Depth Outer Width Tire Type Hub Front Size Rear Size Spoke
Tire Size
(Recommended)
Weight
(+/-3%)
FX165-PRV25-38C-1423 PRV25-38C 38mm 25mm Tubeless or Clincher Novatec A165/A166 9*100mm 10*120mm Pillar 1423 700*25C-45C 1765g
FX165-PRV25-45C-1423 PRV25-45C 45mm 25mm Tubeless or Clincher Novatec A165/A166 9*100mm 10*120mm Pillar 1423 700*25C-45C 1805g
FX165-PRV25-50C-1423 PRV25-50C 50mm 25mm Tubeless or Clincher Novatec A165/A166 9*100mm 10*120mm Pillar 1423 700*25C-45C 1845g
FX165-PRV25-60C-1423 PRV25-60C 60mm 25mm Tubeless or Clincher Novatec A165/A166 9*100mm 10*120mm Pillar 1423 700*25C-45C 1965g
FX165-PRV25-80C-1423 PRV25-80C 80mm 25mm Tubeless or Clincher Novatec A165/A166 9*100mm 10*120mm Pillar 1423 700*25C-45C 2165g


700C Carbon Clincher Rims 25mm Width

Rims PRV25-38C PRV25-45C PRV25-50C PRV25-60C PRV25-80C
Max Weight Limit 110kg/240lb 110kg/240lb 115kg/250lb 120kg/265lb 120kg/265lb
Material T700 T700 T700 T700 T700
Sectional Drawing fixie wheelset flip flop hub 38mm fixie wheelset flip flop hub 45mm 50mm fixie wheelset flip flop hub 60mm fixie wheelset flip flop hub 80mm fixie wheelset flip flop hub

TECHNOLOGY
Carbon Fiber Material

Carbon Fiber Material

Premium Toray T700 + T800 carbon fiber are used in our carbon rims.

Combining with stable resin system to make consistent quality and light weight road carbon rims.

Wider Inner Width

Wider Inner Width

Wider 21mm inner width, optimized for increasingly popular 700x28C tires (also fit even wider tires).

Wider stance for tire, easy tire mounting and dismounting.

Better traction and cornering performance.

Aero U Shape

Aero U Shape

Wide U Shape road carbon rims are more aerodynamic than traditional V Shape road bike rims.

It is also of better stiffness and strength.

Tubeless Ready

Tubeless Ready

Tubeless tire is getting popular in carbon road bike wheelset thanks to its better traction, lower rolling resistance and better riding comfort.

All our carbon clincher rims are tubeless ready (also fit normal tube tires).

Optimized anti-burp bump design provides easy tire mounting, dismounting, as well as air inflation.

Rim Brake

Rim Brake

Road carbon rims designed with high TG brake track for rim brake use. Unique looking small grooves on brake surface.

Small grooves provide more friction, shorten braking distance up to 30%. Faster water clearance, better performance in wet condition.

Small grooves also help to eliminate braking heat faster, better protect the rim in long descending.

Hand Built

Hand Built

All our carbon fiber wheelsets are hand built by experienced mechanician.

Based on customers’ demand, various choice of hubs, spokes and nipples are optional.

After wheel built, they are trued precisely at high standard (≤0.3mm) on roundness, lateral and center tolerance.

Novatec A165/A166 Hubs

Novatec A165/A166 Hubs

Novatec A165/A166 flip flop hubs are used. Carbon Bicycle wheels with great performance and competitive price.

It comes with 17T fixed cog, reliable and stable quality.

Front M9*100mm/Rear M10*120mm Size, with Single Speed compatible.

Pillar Spokes

Pillar Spokes

The popular Pillar PSR AERO 1423 spokes are used.

Pillar patented cold forge technology is applied in the spoke production which increase the strength up to 20%.

Perfect aero shape, high elasticity and low drag coefficient.

2-Year Warranty

2-Year Warranty

We have strict production management system, QC and Testing process. Our quality is always very good and reliable.

For all carbon rims and carbon wheels sold by ProX, 2 years’ quality warranty is offered (starting from the date of package being signed).

Click Warranty Policy to see more details in another page.
