ProX Affordable Carbon Wheelset 98DB Road Disc Brake Carbon Wheels

• 28mm and 25mm wide carbon rims optional

• Economical ProX 98DB hubs, disc brake

• Shimano/Sram 11-12 speed freehub

• Pillar 1423 spokes, aero and strong

• Compatible for 700*25C-45C tire (tubeless ready)

  • Brand:

    PROX

  • Item NO.:

    98DB Clincher Wheels

  • Payment:

    Paypal, Bank Transfer

  • Origin:

    China

  • Color:

    UD/3K/12K(Customized Decal Acceptable)
Inquiry now
DESCRIPTION

ProX Own Mould 98DB Disc Brake Road Wheels - Affordable Carbon Wheelset For Training

Considering the cost of DT Swiss hubs increases quickly, and lead time is getting longer and longer, ProX has developed our own mould disc brake hubs (called 98DB).

ProX carbon road disc wheels 98DB

ProX 98DB road disc brake hubs are designed with 6-pawl freehub system, featuring regular steel bearings. New and improved design of adding the springs to the pawl freehub system which increases efficiency and resilience when pedaling. In that case, the friction is reduced and that can contribute more energy to the wheels. Both center lock and 6-bolt are optional. The end caps of both thru axle( front 12*100mm TA/rear 12*142mm TA) and quick release(QR, front 5*100mm/rear 5*135mm) are also available which allow you to easily switch between different types of bikes or wheels. This is particularly useful if you have multiple bikes with different axle systems or if you frequently change wheels.

In addition, 98DB hubs can be made with your customized logo (either etch logo or make stickers). So it will become your own brand hubs!

ProX 98DB hubs structure and features

ProX provides two width option for our 98DB disc brake carbon road wheels. That is, 28mm width carbon clincher rims, and 25mm width carbon rims clincher.

The 28mm width rim series (model PRD28) is with 28mm outer (21mm inner) width.

For such wide road rims, the optimized aerodynamics tire size is 700*28C. If you plan to use 28C (or wider) tire, PRD28 rim series is recommended.

The 25mm width rim series (model PRD25) is with 25mm outer (18mm inner) width.

For such wide road rims, the optimized aerodynamics tire size is 700*25C. If you plan to use 25C tire, PRD25 rim series is recommended.


6-bolt or Centerlock?

6 bolt or centerlock refer to the attachment between the rotor and hub. As long as the hub is attached to the rotor and centered correctly, both of disc brakes systems will grab your bike and slow you down.
ProX 98DB road hubs are available on both 6 bolt and centerlock options. Below are differences between 6 bolt and centerlock disc brakes.
Hub System 6-bolt  Centerlock
Hub weight 342.7g 332.5g
Pros
             • Compatibility with most rotors；
             • Classic and multiple hubs option；
             • Easy to mount/dismount with a wrench
             • Easy to install or remove；
             • Lightweight on hub(10g/pair)；
             • Rotor is perfectly centered
Cons
     • Takes longer time to (un)install due to 6 bolts
     • Manually centered your 6 bolts rotors
     • Requires special tools for mounting and dismounting
Pictures 6-bolt disc brake road hubs
 centerlock disc brake road hubs
Each system has its pros and cons, and each cyclist should be able to conclude which one is best for themself. The good news is that despite the differences, both the 6-bolt and centerlock can offer great stopping power. 6-bolt or centerlock--the decision is yours!
SPECIFICATION

ProX Own Mould 98DB Disc Brake Carbon Road Wheelset Specification:
-Hub:ProX 98DB disc hubs (front 12*100mm TA/rear 12*142mm TA)

        (The QR end caps/adaptors is available if required)

-Disc brake type: center lock or 6-bolt
-Cassette Body: Shimano 11/12s or Sram 12s XDR optional
-Type: straight pull
-Spoke Hole Count: front 24H/rear 24H
-Tire Type:Clincher/tubeless ready
-Spoke: Pillar 1423 spoke
-Spoke Tension(recommended): ≤145kgf
-Tire Pressure: 125psi/8.6bar
-Warranty Year: 2 years


ProX 98DB Disc Brake Road Carbon Wheels Built With PRD28 Carbon Rims (28mm width)

Model Rim Depth Outer Width Tire Type Hub Front Size Rear Size Spoke
Tire Size
(Recommended)
Weight
(+/-3%)
98DB-PRD28-22C-1423 PRD28-22C 22mm 28mm Tubeless or Clincher ProX 98DB Disc 12*100mm 12*142mm Pillar 1423 700*28C-45C 1431g
98DB-PRD28-33C-1423 PRD28-33C 33mm 28mm Tubeless or Clincher ProX 98DB Disc 12*100mm 12*142mm Pillar 1423 700*28C-45C 1471g
98DB-PRD28-38C-1423 PRD28-38C 38mm 28mm Tubeless or Clincher ProX 98DB Disc 12*100mm 12*142mm Pillar 1423 700*28C-45C 1491g
98DB-PRD28-44C-1423 PRD28-44C 44mm 28mm Tubeless or Clincher ProX 98DB Disc 12*100mm 12*142mm Pillar 1423 700*28C-45C 1531g
98DB-PRD28-50C-1423 PRD28-50C 50mm 28mm Tubeless or Clincher ProX 98DB Disc 12*100mm 12*142mm Pillar 1423 700*28C-45C 1591g
98DB-PRD28-55C-1423 PRD28-55C 55mm 28mm Tubeless or Clincher ProX 98DB Disc 12*100mm 12*142mm Pillar 1423 700*28C-45C 1631g


700C Road Disc Brake Carbon Clincher Rims PRD28 (28mm width)

Rims PRD28-22C PRD28-33C
 PRD28-38C
 PRD28-44C
 PRD28-50C
 PRD28-55C
Max Weight Limit 90kg/198lb
 105kg/230lb
 105kg/230lb
 110kg/240lb
 115kg/250lb
 115kg/250lb
Material T700+T800
 T700+T800
 T700+T800
 T700+T800
 T700+T800
 T700+T800
Sectional Drawing carbon rim drawing PRD28-22C
 carbon rim drawing PRD28-33C
 carbon rim drawing PRD28-38C
 carbon rim drawing PRD28-44C
 carbon rim drawing PRD28-50C
 carbon rim drawing PRD28-55C


ProX 98DB Disc Brake Road Carbon Wheels Built With PRD25 Carbon Rims (25mm width)

Model Rim Depth Outer Width Tire Type Hub Front Size Rear Size Spoke
Tire Size
(Recommended)
Weight
(+/-3%)
98DB-PRD25-30C-1423 PRD25-30C 30mm 25mm Tubeless or Clincher ProX 98DB Disc 12*100mm 12*142mm Pillar 1423 700*25C-45C 1431g
98DB-PRD25-38C-1423 PRD25-38C 38mm 25mm Tubeless or Clincher ProX 98DB Disc 12*100mm 12*142mm Pillar 1423 700*25C-45C 1451g
98DB-PRD25-45C-1423 PRD25-45C 45mm 25mm Tubeless or Clincher ProX 98DB Disc 12*100mm 12*142mm Pillar 1423 700*25C-45C 1511g
98DB-PRD25-50C-1423 PRD25-50C 50mm 25mm Tubeless or Clincher ProX 98DB Disc 12*100mm 12*142mm Pillar 1423 700*25C-45C 1571g
98DB-PRD25-60C-1423 PRD25-60C 60mm 25mm Tubeless or Clincher ProX 98DB Disc 12*100mm 12*142mm Pillar 1423 700*25C-45C 1711g
98DB-PRD25-80C-1423 PRD25-80C 80mm 25mm Tubeless or Clincher ProX 98DB Disc 12*100mm 12*142mm Pillar 1423 700*25C-45C 1991g


700C Road Disc Brake Carbon Clincher Rims PRD25 (25mm width)

Rims PRD25-30C PRD25-38C PRD25-45C PRD25-50C PRD25-60C PRD25-80C
Max Weight Limit 100kg/220lb 110kg/240lb 110kg/240lb 115kg/250lb 115kg/250lb 120kg/265lb
Material T700 T700 T700 T700 T700 T700
Sectional Drawing carbon disc brake road rim 30mm height carbon disc brake road rim 38mm height carbon disc brake road rim 45mm height carbon disc brake road rim 50mm height carbon disc brake road rim 60mm height carbon disc brake road rim 80mm height

TECHNOLOGY
Carbon Fiber Material

Carbon Fiber Material

Premium Toray T700 + T800 carbon fiber are used in our carbon rims.

Combining with stable resin system to make consistent quality and light weight carbon fiber bike rims.

Light Weight

Light Weight

By using well designed lay-up structure, mixing Toray T700 and T800 carbon prepreg, light weight carbon rims are created.

Excessive materials are eliminated to save weight, while extra materials are added around spoke hole for reinforcement.

So, light weight is achieved without compromise in strength or stiffness.

Narrow Inner Width

Narrow Inner Width

Relatively narrow 18mm inner width, make it possible to fit multiple sizes of tire.

Normally road tire size 700x25C and 700x28C are recommended (also fit other wider tires).

Aero U Shape

Aero U Shape

Wide U Shape carbon road rims are more aerodynamic than traditional V Shape carbon road rims.

It is also of better stiffness and strength.

Tubeless Ready

Tubeless Ready

Tubeless tire is getting popular in road bicycle wheels thanks to its better traction, lower rolling resistance and better riding comfort.

All our carbon clincher rims are tubeless ready (also fit normal tube tires).

Optimized anti-burp bump design provides easy tire mounting, dismounting, as well as air inflation.

Road Disc Brake

Road Disc Brake

Road disc brake provides more sensitive and precise braking performance than rim brake.

Carbon fiber road bike rims designed specifically for disc brake use, no brake track. No “burning rim” worries during braking.

Specific carbon prepreg lay-up design for disc brake rims, longer durability and lighter weight.

Hand Built

Hand Built

All our bicycle carbon wheels are hand built by experienced mechanician.

Based on customers’ demand, various choice of hubs, spokes and nipples are optional.

After wheel built, they are trued precisely at high standard (≤0.3mm) on roundness, lateral and center tolerance.

ProX Road Hubs

ProX Road Hubs

ProX own mould 98DB road hubs are used. High quality hubs with cheap price.

98DB road disc brake hubs are designed with 6-pawl freehub system with regular steel bearings.

Such hubs can also be etched with your customized logo.

12*100/12*142 thru-axle, with Shimano 11-speed, Sram 12-speed XDR freehub optional. With 6-bolt, center lock optional.

Pillar Spokes

Pillar Spokes

The popular Pillar PSR AERO 1423 spokes are used.

Pillar patented cold forge technology is applied in the spoke production which increase the strength up to 20%.

Perfect aero shape, high elasticity and low drag coefficient.

2-Year Warranty

2-Year Warranty

We have strict production management system, QC and Testing process. Our quality is always very good and reliable.

For all carbon rims and carbon wheels sold by ProX, 2 years’ quality warranty is offered (starting from the date of package being signed).

Click Warranty Policy to see more details in another page.
